Apache Web Server on Ubuntu 14.04 LTS

The Apache HTTP Web Sever (Apache) is an open source web application for deploying web servers. This guide explains how to install and configure an Apache web server on Ubuntu 14.04 LTS.

If instead you would like to install a full LAMP (Linux, Apache, MySQL and PHP) stack, please see the LAMP on Ubuntu 14.04 guide.

Before You Begin

1. Ensure that you have followed the Getting Started and Securing Your Server guides, and the Linode’s hostname is set.

   To check your hostname run:

   hostname
   hostname -f


   The first command should show your short hostname, and the second should show your fully qualified domain name (FQDN).

2. Update your system:

   sudo apt-get update && sudo apt-get upgrade


Install Apache

Install Apache 2.4, its documentation, and a collection of utilities:

sudo apt-get install apache2 apache2-doc apache2-utils

Configure the Multi-Processing Module

Apache 2.4 offers various multi-processing modules (MPMs) to handle connections. The default MPM is the event module, although the prefork module is still recommended if you’re using standard PHP.

The Prefork Module

1. Open /etc/apache2/mods-available/mpm_prefork.conf in your text editor and edit the values as needed. The following is optimized for a 2GB Linode:

   File: /etc/apache2/mods-available/mpm_prefork.conf

   1 2 3 4 5 6 7 8 9 10 11 12 13 14

   # prefork MPM # StartServers: number of server processes to start # MinSpareServers: minimum number of server processes which are kept spare # MaxSpareServers: maximum number of server processes which are kept spare # MaxRequestWorkers: maximum number of server processes allowed to start # MaxConnectionsPerChild: maximum number of requests a server process serves <IfModule mpm_prefork_module> StartServers 4 MinSpareServers 20 MaxSpareServers 40 MaxRequestWorkers 200 MaxConnectionsPerChild 4500 </IfModule>

2. On Ubuntu 14.04, the event module is enabled by default. Disable it, and enable the prefork module :

   sudo a2dismod mpm_event
   sudo a2enmod mpm_prefork


3. Restart Apache:

   sudo service apache2 restart


The Event Module

If you choose to keep the event module enabled, these settings are suggested for a 2GB Linode.

1. Open /etc/apache2/mods-available/mpm_event.conf in your text editor and edit the values as needed:

   File: /etc/apache2/mods-available/mpm_event.conf

   1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

   # event MPM # StartServers: initial number of server processes to start # MinSpareThreads: minimum number of worker threads which are kept spare # MaxSpareThreads: maximum number of worker threads which are kept spare # ThreadsPerChild: constant number of worker threads in each server process # MaxRequestWorkers: maximum number of worker threads # MaxConnectionsPerChild: maximum number of requests a server process serves <IfModule mpm_event_module> StartServers 2 MinSpareThreads 25 MaxSpareThreads 75 ThreadLimit 64 ThreadsPerChild 25 MaxRequestWorkers 150 MaxConnectionsPerChild 3000 </IfModule>

2. Restart Apache:

   sudo service apache2 restart


Configure Virtual Hosting

Apache supports name-based virtual hosting, which allows you to host multiple domains on a single server with a single IP. Although there are different ways to set up virtual hosts, the method below is recommended.

1. Disable the default Apache virtual host:

   sudo a2dissite 000-default.conf


2. Create an example.com.conf file in /etc/apache2/sites-available with your text editor, replacing instances of example.com with your own domain URL in both the configuration file and in the file name:

   File: /etc/apache2/sites-available/example.com.conf

   1 2 3 4 5 6 7 8

   <VirtualHost *:80> ServerAdmin webmaster@example.com ServerName example.com ServerAlias www.example.com DocumentRoot /var/www/example.com/public_html/ ErrorLog /var/www/example.com/logs/error.log CustomLog /var/www/example.com/logs/access.log combined </VirtualHost>

   Repeat this process for any other domains you host.

   Note

   If you would like to enable Perl support, add the following lines above the closing </VirtualHost> tag:

   File: /etc/apache2/sites-available/example.com.conf

   1 2	Options ExecCGI AddHandler cgi-script .pl

3. Create directories for your websites and websites’ logs, replacing example.com with your own domain information:

   sudo mkdir -p /var/www/example.com/public_html
   sudo mkdir /var/www/example.com/logs


4. Enable the site:

   sudo a2ensite example.com.conf


5. Restart Apache:

   sudo service apache2 restart


Apache Mods and Scripting

Install Apache Modules

One of Apache’s strengths is its ability to be customized with modules. The default installation directory for Apache modules is the /etc/apache2/mods-available/ directory.

1. List available Apache modules:

   sudo apt-cache search libapache2*


2. Install any desired modules:

   sudo apt-get install [module-name]


3. All mods are located in the /etc/apache2/mods-avaiable directory. Edit the .conf file of any installed module if needed, then enable the module:

   sudo a2enmod [module-name]


   To disable a module that is currently enabled:

   a2dismod [module-name]


Optional: Install Support for Scripting

The following commands install Apache support for server-side scripting in PHP, Ruby, Python, and Perl. Support for these languages is optional based on your server environment.

To install:

• Perl support:

  sudo apt-get install libapache2-mod-perl2


• Python support:

  sudo apt-get install libapache2-mod-python


• PHP support:

  sudo apt-get install libapache2-mod-php5 php5 php-pear php5-xcache


More Information

You may wish to consult the following resources for additional information on this topic. While these are provided in the hope that they will be useful, please note that we cannot vouch for the accuracy or timeliness of externally hosted materials.

• Apache HTTP Server Version 2.4 Documentation
• Apache Configuration
